Do you have an application where you transfer delicate materials through your warehouse presented on a a-frame? How about tow carts that are transported by an AGV? Are you concerned about down time, pulling forces and trailability? Are you in the market for a tough and durable trailer? Have you had an experience where other manufacturer's trailers just didn't hold up?
Does the size and shape of your material change often? Would you like a modular way to support the load?
If so check out XT3508 below, and see how it filled our customer's material handling needs. Hamilton has years of experience and expertise in the design and manufacturing of custom material handling carts and trailers.
Statement of Understanding -
Customer is seeking a design for an effective way to store, transport, and display unique and delicate tubing with the intent to acquire and utilize many units indefinitely. This towable cart will be designed to easily secure and transport custom tubing around the factory. The minimum length must accommodate 8' long tubing and have an accessible shelf underneath. It will be pulled 200 yards by AGV in Warehouse, rolled onto factory floor 300+ yards by a technician, and stored safely on floor for up to 72 hours.
Cart Specifications -
Hamilton model number - XT3508
Frame Construction - Structural steel open frame, A-frame with perforated sheet on each side.
Superstructure - Double sided A-frame with 48" x 96" perforated sheet.
Steering Type - Caster Steer
Deck Size - 33" x 96"
Deck Height - 10-1/2".
Overall Height - 71-1/2
Capacity - 500 lbs
Trailer Weight – 610 lbs
Running Gear – (2) S-WH-62EMB / (2) S-WH-62EMB-4SL Swivel casters.
Couplers – Loop type towing tongue
Finish – Safety Yellow enamel
Stenciling - Load Capacity stenciled on each side.
Customer Profile -
The customer is the most experienced space launch company in the US. They have over 150 consecutive launches with a 100% mission sucess rate.
With two launch sites, and three other facilities that house engineering, manufacturing, testing and mission support, the customer employs about 2,700 employees.
