Rest assured, this trailer is strapped in for success


In industrial transport, flexibility and foresight separate the elite haulers from the rest. That’s why Hamilton doesn’t just build trailers—we engineer solutions that adapt.

Take our latest custom Hercules Fifth-Wheel Steer Trailer, designed for a specialty steel manufacturer to haul an 1,850-gallon free-standing tank safely across its campus. This beast—83 inches wide, 144 inches long, and rated for 20,000 pounds—is designed for power towing, rolling smoothly on press-on polyurethane wheels over concrete and asphalt.

The tank stays locked down with four structural steel straps, while internal baffles prevent liquid slosh for a steady ride at 3-5 MPH. And when it’s time to park? A tongue-actuated brake automatically engages when the tongue is stowed upright.

By mounting the tank ourselves during the build to ensure a proper fit, Hamilton caught a mismatch between the straps and the tank—a discovery that saved the customer from costly delays and rework. That’s why we engineer adaptability into every design. Need a perfect fit? We’ll mount your equipment in-house. Need custom mounting holes or added bracing? Consider it done.

That’s precision on lockdown.

XT3654 – Hercules Fifth-Wheel Steel Trailer

  • Capacity: 20,000 lbs.
  • Deck Size: 83" Wide x 144" Long
  • Operating Environment: Concrete/Asphalt around client's campus
  • Deck Height: 24 1/2"
  • Steering Type: Fifth Wheel
  • Running Gear: 15" (Front) & 18" (Rear) dia. press-on polyurethane wheels
  • Couplers: Loop type towing that includes parking brake when stowed in the upright position.
  • Finish: Yellow
